AMPD BROS ACE-S PLUS+
Couldn't load pickup availability
Description
Introducing the ACE-S Plus+ Electric Fat Tyre Bike – Elevate Your Adventure!
Unveiling the ACE-S Plus+, a high-performance, high octane variant of our ACE-S model that takes your riding experience to new heights. This upgraded version features front suspension forks, delivering a smoother ride across diverse terrains. Equipped with a larger more powerful 750W Bafang Rear Hub Motor, it boasts a higher top speed, allowing you to conquer every trail with ease.
Revamped and refined, the ACE-S Plus+ Electric Bike redefines your riding experience with its sleek Low Bar Step Through frame design, ensuring easy access and unparalleled comfort. Originating from our popular ACE-X model, the ACE-S maintains the robust construction that sets it apart.
Designed in conjunction with our in-house family team and continuously sought after since its debut in 2019, the ACE Bike continues to create waves nationwide.
Loaded with premium features and celebrated year after year as Australia's favourite fat tyre bike the ACE range boasts a Shimano 7 Speed Derailleur, vibrant colour options and a cutting-edge battery system with our Latest GEN3 Aluminium Battery which encompasses 21700 cells that are 30% larger than our competitors, paired with a Smart BMS for optimal performance and safety.
The ACE-S Plus+ takes performance up a notch with our Custom Master Control unit, providing top-tier power density and advanced motor control algorithms. Seamlessly integrating light controls, improving reliability and simplifying diagnostics, this bike is powered by Bafang's High Torque Motor, ready to conquer diverse terrains.
What's New for 2024?
- NEW GEN3 Battery with Integrated Tail & Brake Lights
- Increased Battery Capacity to 20AH
- Increased Motor from 500W to 750W
- Updated 30% Larger Battery Cells to Premium Samsung 21700 Cells
- Integration of Bafang's Latest Gen Hub Motor
- Frame Design Improvements caters for our new Series 3 Rear Cargo Rack & Internal Frame Basket System installation
The ACE-S ensures no adventure is off-limits, accommodating two riders with its spacious seat. The removable Samsung Battery delivers an incredible 80km range on a single charge. From beaches to hills, dirt tracks to pavements, the ACE-S handles it all effortlessly. Opt for the Off-Road Throttle Kit for cruising ease, and embrace rapid gear shifts with the Shimano Rapid Fire shifter and Altus transmission.
Join the ACE revolution and unlock limitless possibilities with the ACE-S Electric Fat Tyre Bike – your ticket to exhilarating adventures awaits!
Checkout the Range of Options & Accessories for your New ACE Bike or need help customising your bike? Speak to our Friendly Team on what works best for you.
Specs
SPEED & RANGE
- Range Standard Models 60km
- Range Plus & Rally Models 80km
- Top Speed Standard Models 38km/h (Off Road Use Only)
- Top Speed Plus & Rally Models 45km/h (Off Road Use Only)
- Note: All Models are Locked to 25km/h and can be Unlocked to max for Off Road Private Property Use only.
BATTERY
- Standard Models 48V / 720Wh, 15AH
- Plus+ & Rally Models 48V / 960Wh, 20AH
- Samsung Premium 21700 Lithium cells
- Battery is removable and can be charged in bike or separately.
RIDE MODES
- Mode 1 Pedal Assist mode: Adjustable pedal assist performance settings from 1-5 or can also be changed to 1-3 or 1-9
- Mode 2 Walk mode: Idles bike up to 6km/h to assist with moving bike by holding the "-" button on the keypad
- Mode 3 Throttle mode: Available when Optioned with the Off Road Throttle Kit
FEATURES
- Hill Ability Up to 15º Degree / 25% Incline PAS
- Seat Custom Large Black Dual Seat for 2 Riders (Brown on Classic Models)
- Lights Front LED 220lm Headlight with DRL
- Lights Rear LED Brake Light inbuilt to battery pack
- Grips Black Velo Wide Comfort (Brown on Classic Models)
- Bell Yes
BRAKES
- All Models Tektro Hydraulic Disc
- Discs 160mm
- E-Brakes Yes Motor Safety Cut Off
DISPLAY
-
LCD Multi-Function with USB, ODO, Trip, Battery Level, Speed etc
CONTROLLER
-
Ampd Brothers Custom - Best-in-class power density and state-of-the-art motor control algorithms.
DRIVETRAIN
- Electric Motor Bafang RMG062 Latest Generation Rear Hub Drive
- Power Output 500W - 65N.m Standard Models
- Power Output 750W - 80N.m Plus+ & Rally Models
- Transmission Shimano 7 Speed with Rapid Fire Micro Shifter
- Derailleur Shimano Altus
- Pedals Wellgo Alloy - Black
- Chain KMC Z Series High Performance
CONSTRUCTION
- Frame Aluminium - "X" Step Over or "S" Step Through Low Bar Designs
- Handlebars Aluminium Motorcycle Inspired with Adjustable Height
- Fenders Matte Black Aluminium
SUSPENSION
- Standard Models No Suspension
- Plus+ & Rally Models Front Independent
WHEELS & TYRES
- 20x4.0" Kenda Krusade Fat Mud Tyres
- 20x4.0" CST Tourance Fat Street Tyres (Rally Plus+ Models Only)
CHARGING
- 7-8hrs 15Ah Batteries with Standard 2A Included Charger
- 9-10hrs 20Ah Batteries with Standard 2A Included Charger
- Optional 5A Fast Charger Available for 2.5x Faster Charging
DIMENSIONS
- Overall Length 1,750 mm
- Handlebar Height 1,140 - 1,190 mm
- Handlebar Width 660 mm
- Seat Height 810 mm Fixed Height
- Seat Length 600 mm
- Ground Clearance 270 mm
- Wheel Base 1,160 mm
- Rider Height Ideal for Riders up to 200cm Tall
WEIGHTS
-
N.W of 15Ah Battery 4.34 kg
- N.W of 20Ah Battery 5.12 kg
- N.W of Standard ACE + Battery 32.3 kg
- N.W of ACE Plus/Rally + Battery 36 kg
- Max Loading 150 kg
INCLUSIONS
-
In Box Bike, 48V Battery, 2A AUS Charger, Front Headlight, Basic Tool Kit, Manual, Pedals, Fenders, Seat & Kick Stand.
*Range Achievable may vary based on loading, motor use, throttle/pas, terrain, weather conditions and many other factors.
Models
ACE MODELS - SO WHATS THE DEAL?
What does X & S mean?
- X means "Cross Bar Step Over Frame" and
- S means "Step Through, Low Bar Frame"
ACE VS ACE Plus+
- Standard "ACE" Consists of a 500W Motor, No Suspension and a 15AH or "60km" Range Battery Pack where,
- ACE Plus+ Models Consist of the same features as the standard ACE range but instead with Bigger 750W Motor, Front Suspension and a 20AH or "80km" Range Battery Pack
ACE Rally Series
The ACE-X Rally features the same specifications as a Plus+ Model, but with a few differences primarily in styling such as;
- Unique Paint Finishes exclusive to the Rally Series Only
- Bafang 750W Motor
- Custom Rally Edition Headlight & Seat
- Unique CST Street Tyres instead of Kenda Mud Tyres
ACE-X Pro Series
The ACE-X Pro series is the entry level model into our dual suspension line. The Pro also receives a bunch of upgrades from the Plus+ Series including;
- Unique Paint Finishes exclusive to Pro Models Only
- Upgraded 1,000W Rear Hub Drive Motor
- Upgraded Display to a Full Colour LCD
- Upgraded to Dual Suspension with DNM Rear Shock
- Upgraded Battery Pack to 25Ah with up to 100km Range
ACE-X Demon Series
The ACE-X Demon series is the bigger brother of the ACE Pro, consisting of much the same bones as the Pro, although with some major bonus'...
- Unique Paint Finishes exclusive to Demon Models Only
- Upgraded from Single Motor to Dual AWD Hub Motors (1,000W Front & Rear - Total 2,000W)
- Upgraded Headlight to our Extreme 1,700lumen LED Light
